| Place of Origin: | China |
|---|---|
| Brand Name: | TX TELSIG |
| Certification: | CE FCC ROHS SGS |
| Model Number: | TX-JZ01 |
| Document: | Anti Drone product-TeXin.pptx |
| Minimum Order Quantity: | 1 |
| Price: | Negotiated USD or RMB |
| Packaging Details: | Durable Alluminum alloy case with wooden case outside |
| Delivery Time: | in 2 days |
| Payment Terms: | T/T,Paypal, Etc. |
| Supply Ability: | 50,000pcs/month |
| Type: | UAV DRONE RF Signal Jammer | Range: | Radius 1000 To 3000 Meter |
|---|---|---|---|
| Output Power: | 190W/Customized | Antenna: | 16dBi For Each Band |
| Power Case: | IP64 Level | Color: | Grey |
| Power Supply: | AC110-240V To DC27V | Duration Time: | Continuous 24hour |
| Case Size: | 38.5*30.7*15.6cm(not Including Antenna) | Product Weight: | 10.0kgs(antenna Not Included ) |
| Installation Height: | 3 To 18 Meter | Material: | Aluminium |
| Channel: | 6-8channel | ||
| Highlight: | wifi jamming device,wifi signal scrambler,Oil Depot Signal Jammer Blocker |
||
Outdoor computer connection long range UAV drone signal jammer blocker for oil depot
Description
This is a high power operate aluminum- made anti drone jammer device ,it takes radio frequency technology that can block drone signal around 1000-3000 meter .The jammer match 5 high gain antennas ,and the rf modules support customization so that users can freedom of choice.
Function
1. It can protect an area radius 1000-3000 meter away from UAV drone by stop remote control of wifi signal and GPS signal.
2. UAV status: no signal, no network, stop data and video transmission, stop action, land or return home
3. We can do 5.8G RF jammer module 40W or 50W, other module over 100W
Feature
1. Ultra high power 190W, combined with high gain directional antenna for each band
to shield radius 1000 to 3000 meter area (depends on real environment and signal strength)
2. 3 channel or More channel signal shielding IP64 level main control engine, or other customized frequency 433MHz, 868MHz, 912MHz, 916MHz, GPS/Glonass navigation signal,
3. Seperate fequency RF module and Single Switch control to exactly shield specific signal
also for customized frequency and easy maintainance
4. Efficient heat dissipation system: fast blow heat away to ensure long time operation
5. Optional monitoring software monitoring for client : can support PC operation, phone APP control,
drone detecting integrated system
6. VSWR protection: use power supply protection box, to ensure stable and safe power supply
7. Huawei latest high tech thunder protection box
8. Only influence downlink; No influence to base station
|
|
Main Engine Case
1. IP64 level die cast alluminum alloy design, Hinge lock protection for easy management and and anti-damage
2. N type connector(customized) to link with Antenna
3. Efficient heat dissipation system with built in fan and fin
4. Main switch to control the complete device work
5. Optional choice for directional or omni fiberglass antenna
6. Seperate module design, For single frequency control
7. LED indicates the working-on status
8. Over temperature and VSWR protection with power supply protection box
9. Please Ensure the anntenna is connected before turning power on
Optional Frequency (10W, 20W,30W,40W, 50W, 100W; RF module also available )
CDMA/GSM850MHz:850-894MHz; 100W;
GSM900MHz:925-960MHz; 100W;
GSM/DCS1800MHz:1805-1880MHz; 100W;
3G/UMTS2100MHz:2110-2170MHz; 100W;
4GLte700MHz:790-826MHz; 100W;
4G/WiMAX2600MHz:2620-2690MHz; 100W;
WIFI2.4G:2400-2485MHz; 100W;
4G2500MHz:2500-2570MHz; 100W;
GPSL1:1570-1610MHz; 100W;
GPSL2:1200-1300MHz; 100W;
GPSL3:1380-1400MHz; 100W;
Wi-Fi5.8GHz:5725-5850MHz; 10W;
VHF:135-174MHz; 100W
UHF:400-470MHz; 100W
RC433MHz:433MHz; 100W
RC315MHz:315MHz; 100W
17.CDMA450MHz:450-470MHz; 100W;
Tests
Long time Aging test and Repeated Spectrum Analyzer tests to ensure products qualified
Installation Reference:
Different Solution:
Main Engine , Antenna ,Coxial, Connectors,etc.
Details Photo
Technical Data:
|
Model |
TX-JZ01 |
|
Jamming radius |
1000-3000 meter |
|
Output Power |
Total 190W |
|
Standard Shield Frequency |
GPSL1: 1560-1620MHz |
|
Wifi 2.4G: 2400-2485MHz |
|
|
Wifi 5.8G: 5725-5850MHz |
|
|
(Other customized frequency) |
|
|
Power consumption |
380W |
|
Size |
53*41*23cm |
|
Antenna size |
124*28*8cm |
|
Working Hour |
Continuous Working |
|
Ambient Temperature |
-40℃～75℃ |
|
Relative Humidity |
35～85% |
|
Installation Height |
3～15meter |
|
Installation ways |
Wall hanging/pole holding |
|
Outshell material |
Die Cast Aluminium alloy |
|
Waterproof Level |
IPX64 |
Antenna Data:
|
FrequencyRange |
Can be customized |
|
Dimensions*mm(Height/Width/Depth) |
124*28*8cm (Customized) |
|
Gain |
16±1dBi (Customized) |
|
VSWR |
≤1.5 |
|
Polarization |
Vertical |
|
Horizontal Beamwidth(0º) |
100±5º |
|
Vertical Beamwidth(0º) |
15±3º |
|
Front-to-back ratio(dB) |
≥25 |
|
Input Impedance(Ω) |
50Ω |
|
Maximum input power(W) |
100W for single connector |
|
Input connector type |
N type or customized |
|
Lightening Protection |
DC Ground |
|
Rated Wind Velocity(m/s) |
60m/s |
|
Operational Humidity(％) |
10- 95 |
|
Radome Color |
Gray Color |
|
Radome material |
UPVC |
|
Operating temperature(ºC) |
-30～75 º |
|
Installution Method |
Pole Mount |
|
Mounting hardware(mm) |
￠40～￠80 |
|
Mechanical tilt(º) |
0-10º |
