| Place of Origin: | China |
|---|---|
| Brand Name: | TX TELSIG |
| Certification: | SGS,ISO9001 |
| Model Number: | TX-TC119 |
| Document: | Factory Introduce.pdf |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Durable Case or Box or Customized |
| Delivery Time: | 2 work day |
| Payment Terms: | T/T,Paypal,L/C,D/A,D/P, Etc. |
| Supply Ability: | 100,000pcs/month |
| Frequency Range: | 300-6300MHz | Main Frequency: | 868mhz 915mhz 2.4ghz 5.8ghz |
|---|---|---|---|
| Range: | 1000-2000m | Working Time: | 6-8 Hours |
| Weight: | 270g | Application: | DJI FPV |
| Antenna: | Directional Antenna | Charging: | USB |
| Size: | 118 × 60 × 35mm | ||
| Highlight: | wireless camera detector,wifi signal strength detector |
||
Hand held portable DJI fpv drone detector range 1000-2000m USB charging
The handheld portable DJI FPV drone detector using self-developed low-power digital analog hybrid receiver technology and advanced power management technology, as well as external ultra-wide band antennas, it is possible to accurately achieve acoustic, optical, and vibration warnings for commonly used civil unmanned aerial vehicles, including four-quar, fixed wing, DIY, and traversing aircraft, while achieving extremely low false alarm rates in complex electromagnetic environments.
During use, it can reach an ultra-long detection distance of 1-2km, with long use time, high sensitivity, simple operation and convenient to carry. It is an effective tool for outdoor safety protection.
Feature
1. Produced and designed by Texin Factory Origin: China
2. Small size and light structure, with buckle, can be carried with you
3. 300-6300MHz Full frequency band coverage, suitable for most drone models on the market
4.1-2km super long distance detection
5.USB charging fast charging, low power consumption, long use time
6.High gain directional antenna matched
| Aim drone type | DJI,AUTEL ,and four rotor,fixed wing,FPV |
|
Frequency range
|
2400-2485MHZ(B1OFDM hd image transmission)
|
|
5150-5350MHZ(B2FDM,hd image transmission)
|
|
|
5725-5850MHZ(B3OFDM,hd image transmission)
|
|
|
5360-5975MHZ(B4FPV,simulation image transmission)
|
|
|
700-1500MHZB5,simulation image transmission)
|
|
| Working distance |
＞1km(B1, B2, B3 take DJI MAVIC2 Visual environment high 50m as the standard,B4,B5take FPV Visual environment high 600m as standard) |
| Alarm way | Voice/lighting/shocking |
| Power supply mode |
Replaceable 18650 lithium battery
|
| Battery | ＞8h(piece) |
| Charge | battery charge or connect USB TYPE-C |
| Charging voltage | DC5V |
|
Size |
118 × 60 × 35mm |
|
Weight |
270g (including one battery) |
Specification
1. Package Size: 118 × 60 × 35mm
2. Net Weight: 270g
3. Application : DJI,AUTEL,FPV
4. Working distance : 1-2km
5. Battery: 18650 lithium battery
6. Continuous Operation: 8-10 hours
7. Charging Time: 1-2hours
Application
Important locations and facilities, such as airports, pubic procuratorate system, prisons, detention centers, drug rehabilitation centers, security agencies, troops, large events, concerts, important meetings, government agencies and anti-terrorism fields, need space confidentiality and no drone control.
Full Set Package
Detector*1
Battery*2
OMNI antenna*3 (The longer the antenna, the higher the gain, the higher the sensitivity, and the farther the detection distance can be. )
Charging Base*1
Power Charger*1
